EN50620 Cables
Mechanical Performance：
Sheath: TPU
Condutor: Copper
Environment Performance:
Operating temperature: -40℃~+90℃
Electrical performance:
Rated current: 450/750V
Withstand voltage: AC2.5kV/5min
Insulation resistance: ≥3670mΩ · km (20℃）
Product description
Conform to the latest provisions and requirements of IEC 62196-2 and EN50620
Flexibility and Elasticity
Non-toxic and Environment-friendly polymer
High strength, Wear resistance, Cold resistance, High-temperature resistance
Oil resistance, Water resistance, Aging resistance
Customized cables according to customer requirements
Our advantage
Parameter
|
EN50620 H07BZ5-F |
|||
|
Code |
Type |
Rated Current/voltage |
Cable Specification |
|
9001 |
AP-H07BZ5-F 3*2.5+2*0.5 |
16A/250V |
3*2.5mm²+2*0.5mm²/OD 10.2±0.3mm/Black |
|
9002 |
AP-H07BZ5-F 3*6+2*0.5 |
32A/250V |
3*6mm²+2*0.5mm²/OD 12.8±0.3mm/Black |
|
9003 |
AP-H07BZ5-F 5*2.5+2*0.5 |
16A/480V |
5*2.5mm²+2*0.5mm²/OD 12.8±0.3mm/Black |
|
9004 |
AP-H07BZ5-F 5*6+2*0.5 |
32A/480V |
5*6mm²+2*0.5mm²/OD 16±0.3 mm/Black |
|
Statement：The cable length can be customized according to your demand |
|||
About Us
AP Team focuses on the product design, development, marketing and supply chain integration of new energy electrical connection. The team has over 20 years of experience in the industry and served multiple well-known domestic and global new energy partners including famous vehicle manufacturers, and electrical connectivity company.
