Mechanical properties:
Display: 5-inch display
Input cable length: 0m (customizable)
Cable length : 3m (customizable)
Weight:20KG/25KG/28KG
Size (mm): 450*150*310/500*200*320
Certification: CE, ROHS
Interface standard: CCS /CHADEMO /GB/T
Product description
(1) Easy to carry, small size, and lightweight
(2) Unique patented technology, high protection level for outdoor use, and high heat dissipation efficiency
(3) Support CCS-2/CCS-1/CHAdeMO connector (socket) optional
(4) Support Ethernet or wireless communication
(5) Exquisite appearance, simple operation, and easy installation
(6) Interactive interface, 5-inch screen
Our advantage
Parameter
DC movable charger-MD |
|||||
Code |
Type |
Output power(KW) |
Output current(A) |
Input current(A) |
Display |
17001 |
AP-TA-DC-7MD |
7 |
20 |
32 |
5-inch display |
17002 |
AP-TA-DC-14MD |
14 |
20 |
32 |
|
17003 |
AP-TA-DC-15MD |
15 |
25/37 |
25 |
|
17004 |
AP-TA-DC-20MD |
20 |
32 |
32 |
|
17005 |
AP-TA-DC-30MD |
30 |
16 |
45 |
|
Charging protocol:GBT27930/CHADEMO 2.0/ DIN 70121 OCPP 1.6(JSON)/ISO15118 |
About Us
AP Team focuses on the product design, development, marketing and supply chain integration of new energy electrical connection. The team has over 20 years of experience in the industry and served multiple well-known domestic and global new energy partners including famous vehicle manufacturers, and electrical connectivity company.
FAQ
